| PartNumber | VVX21F136J00 |
| Značka | Panasonic |
| Velikost | 21.3 |
| aplikace | MD |
| Rozlišení | 1600×1200 |
| Složení | LCM |
| Jas | 400 |
| CR | 1400:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | Panasonic |
| panelový model | VVX21F136J00 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 21.3 inch |
| rozlišení | 1600(RGB)×1200 , UXGA |
| zobrazovací mód | IPS, Normally Black, Transmissive |
| aktivní oblast | 432×324 mm |
| obrys | 456×349.5×22.8 mm |
| povrch | Antiglare |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 1400:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193175% |
| Doba odezvy | 11/9 (Typ.)(Tr/Td) |
| úhel pohledu | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 11S5PWLEDWithout Driver |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | MD |
| LTM213U3-L07 | Samsung | 21.3 | 1600×1200 |
| LTM213U6-L01 | Samsung | 21.3 | 1600×1200 |
| NL160120AC27-37 | NLT | 21.3 | 1600×1200 |
| NL160120BM27-03A | NLT | 21.3 | 1600×1200 |
| NL204153BM21-01A | NLT | 21.3 | 2048×1536 |
| R213RFE-L01 | Innolux | 21.3 | 2048×1536 |
| R213T3-L01 | Innolux | 21.3 | 2560×2048 |
| R213T3-L02 | Innolux | 21.3 | 2560×2048 |
| TX54D11VC0CAB | JDI | 21.3 | 1600×1200 |
| VVX21F136J00 | Panasonic | 21.3 | 1600×1200 |
| G213QAN01.0 | AUO | 21.3 | 2048×1536 |
| NL160120BM27-03A | NLT | 21.3 | 1600×1200 |
| NL160120BM27-07 | NLT | 21.3 | 1600×1200 |
| NL204153AC21-09 | NLT | 21.3 | 2048×1536 |
| NL204153BM21-04A | NLT | 21.3 | 2048×1536 |
| R190E5-L01 | Innolux | 19.0 | 1280×1024 |
| R190EFE-L51 | Innolux | 19.0 | 1280×1024 |
| R196U2-L01 | Innolux | 19.6 | 1600×1200 |
| R213RFE-L01 | Innolux | 21.3 | 2048×1536 |
| VVX28T143H00 | Panasonic | 28.0 |
