| PartNumber | A035QN05 V1 |
| Značka | AUO |
| Velikost | 3.5 |
| aplikace | PP |
| Rozlišení | 320×240 |
| Složení | LCM |
| Jas | 300 |
| CR | 300:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | Serial RGB |
| značka panelu | AUO |
| panelový model | A035QN05 V1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 320(RGB)×240 , QVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 70.32×52.74 mm |
| obrys | 76.9×63.9×3.12 mm |
| povrch | Hard coating |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 300:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193145% |
| Doba odezvy | 10/15 (Typ.)(Tr/Td) |
| úhel pohledu | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 6S1PWLEDWithout Driver |
| signálové rozhraní | Serial RGB (8-bit) + SPI, 50 pins |
| vstupní napětí | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| aplikace | PP |
