| PartNumber | C035QVN01.0 |
| Značka | AUO |
| Velikost | 3.5 |
| aplikace | CNS |
| Rozlišení | 240×320 |
| Složení | LCM |
| Jas | 450 |
| CR | 1000:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | AUO |
| panelový model | C035QVN01.0 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 240(RGB)×320 , QVGA |
| zobrazovací mód | AMVA, Normally Black, Transmissive |
| aktivní oblast | 53.28×71.04 mm |
| obrys | 69.22×87.2×21 mm |
| povrch | Antiglare |
| jas | 450 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Min.) |
| zobrazit barvy | 262K (6-bit), CIE193170% |
| Doba odezvy | 10/25 (Typ.)(Tr/Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 2S2PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit), 50 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | CNS |
