| PartNumber | AM-800480LTMQW-00H-F |
| Značka | AMPIRE |
| Velikost | 5.0 |
| aplikace | IA |
| Rozlišení | 800×480 |
| Složení | LCM |
| Jas | 450 |
| CR | 250:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | AMPIRE |
| panelový model | AM-800480LTMQW-00H-F |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.0 inch |
| rozlišení | 800(RGB)×480 , WVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 108×64.8 mm |
| obrys | 119×77.1×3.41 mm |
| povrch | Glare (Haze 0%) |
| jas | 450 cd/m² (Typ.) |
| kontrastní poměr | 250:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193152% |
| Doba odezvy | 15/35 (Typ.)(Tr/Td) |
| úhel pohledu | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 3S6PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 8-bit), 45 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | IA |
