| PartNumber | HSD050I551-A00 |
| Značka | HannStar |
| Velikost | 5.0 |
| aplikace | VDP |
| Rozlišení | 320×234 |
| Složení | LCM |
| Jas | 400 |
| CR | 350:1 |
| Barvy | |
| Podsvícení | CCFL |
| Rozhraní | Analog |
| značka panelu | HannStar |
| panelový model | HSD050I551-A00 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.0 inch |
| rozlišení | 320(RGB)×234 |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 102.72×74.53 mm |
| obrys | 119.3×91.4×7.8 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 350:1 (Typ.) |
| zobrazit barvy | |
| Doba odezvy | 5/20 (Typ.)(Tr/Td) |
| úhel pohledu | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 1 pcsCCFLWithout Driver |
| signálové rozhraní | TFT Specific Analog RGB, 30 pins |
| vstupní napětí | 3/5/15/-10V (Typ.)(DVDD/AVDD/VGH/VGL) |
| rohs: | |
| aplikace | VDP |
