| PartNumber | LQ043T1DG28 |
| Značka | SHARP |
| Velikost | 4.3 |
| aplikace | HHP |
| Rozlišení | 480×272 |
| Složení | LCM |
| Jas | 300 |
| CR | 500:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | SHARP |
| panelový model | LQ043T1DG28 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 4.3 inch |
| rozlišení | 480×272(RGB) , WQVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 95.04×53.856 mm |
| obrys | 105.5×67.2×4.45 mm |
| povrch | Antiglare, Hard coating (2H) |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 22/8 (Typ.)(Tr/Td) |
| úhel pohledu | 80/80/55/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 9S1PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit) + SPI, 67 pins |
| vstupní napětí | 3.3/3.3V (Typ.)(IOVCC/VCC) |
| aplikace | HHP |
| LQ043T1DG28 | SHARP | 4.3 | 480×272 |
| LQ043T1LX01A | SHARP | 4.3 | 540×960 |
| LQ043T3DX02 | SHARP | 4.3 | 480×272 |
| LQ043T3DX03 | SHARP | 4.3 | 480×272 |
| LQ043T3DX03A | SHARP | 4.3 | 480×272 |
| LQ043T3DX04 | SHARP | 4.3 | 480×272 |
| LQ043T3DX0F | SHARP | 4.3 | 480×272 |
| LQ043T3DX0G | SHARP | 4.3 | 480×272 |
| LQ043T3LX02 | SHARP | 4.3 | 480×272 |
| LQ043Y1DX01B | SHARP | 4.3 | 480×800 |
| 32NHF0H | SII | 3.2 | 360×640 |
| 32WVF0H | SII | 3.2 | 480×800 |
| A043FW03 V2 | AUO | 4.3 | 480×272 |
| COM35H3M10XTC | ORTUSTECH | 3.5 | 240×320 |
| G043FTT01.0 | AUO | 4.3 | 480×272 |
| LQ043T1DG28 | SHARP | 4.3 | 480×272 |
| TFTMD030035 | JDI | 3.0 | 640×480 |
| TM030ZDHG01 | Tianma | 3.0 | 320×320 |
| TM035HDHT1 | Tianma | 3.5 | 240×320 |
| TX09D40VM3CBA | KOE | 3.5 | 240×320 |
