| PartNumber | HX104X01-210 |
| Značka | HYDIS |
| Velikost | 10.4 |
| aplikace | PAD |
| Rozlišení | 1024×768 |
| Složení | LCM |
| Jas | 300 |
| CR | 600:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | HYDIS |
| panelový model | HX104X01-210 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 10.4 inch |
| rozlišení | 1024(RGB)×768 , XGA |
| zobrazovací mód | AFFS+, Normally Black, Transmissive |
| aktivní oblast | 210.4×157.8 mm |
| obrys | 238.6×173.2×6.8 mm |
| povrch | Antiglare |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 600:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193140% |
| Doba odezvy | 36 (Typ.)(Tr+Td) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 7S6PWLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (1 ch, 6-bit), 30 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | PAD |
