| PartNumber | LQ065T5DG05 |
| Značka | SHARP |
| Velikost | 6.5 |
| aplikace | CNS |
| Rozlišení | 480×234 |
| Složení | LCM |
| Jas | |
| CR | |
| Barvy | 262K |
| Podsvícení | CCFL |
| Rozhraní | TTL |
| značka panelu | SHARP |
| panelový model | LQ065T5DG05 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 6.5 inch |
| rozlišení | 480(RGB)×234 |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 142.6×80.7 mm |
| povrch | |
| jas | |
| kontrastní poměr | |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | |
| úhel pohledu | |
| typ lampy | 1 pcsCCFL |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit) |
| rohs: | |
| aplikace | CNS |
| LQ065T5AR05 | SHARP | 6.5 | 400×234 |
| LQ065T5BR08 | SHARP | 6.5 | 400×240 |
| LQ065T5DG30 | SHARP | 6.5 | 400×240 |
| LQ065T5GA01 | SHARP | 6.5 | 400×234 |
| LQ065T9BR51U | SHARP | 6.5 | 400×240 |
| LQ065T9BR54U | SHARP | 6.5 | 400×240 |
| LQ065T9DR52U | SHARP | 6.5 | 400×240 |
| LQ065T9DZ03 | SHARP | 6.5 | 400×240 |
| LQ065Y5DG01 | SHARP | 6.5 | 800×480 |
| LQ065Y5DG03 | SHARP | 6.5 | 800×480 |
| 70WVW1A | SII | 7.0 | 800×480 |
| A070FW03 V6 | AUO | 7.0 | 480×234 |
| A102VW01 V7 | AUO | 10.2 | 800×480 |
| C070VW04 V6 | AUO | 7.0 | 800×480 |
| C090EAN01.1 | AUO | 9.0 | 1280×720 |
| CLAA062LA01CW | CPT | 6.2 | 800×480 |
| LB070WQ4-TM06 | LG Display | 7.0 | 480×234 |
| LQ080Y5DG03 | SHARP | 8.0 | 800×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| YXDK050TN02-40NM03 | SEBO | 5.0 | 800×480 |
