| PartNumber | LQ070T5BG01 |
| Značka | SHARP |
| Velikost | 7.0 |
| aplikace | VDP |
| Rozlišení | 480×234 |
| Složení | LCM |
| Jas | 300 |
| CR | 60:1 |
| Barvy | Full color |
| Podsvícení | CCFL |
| Rozhraní | Analog |
| značka panelu | SHARP |
| panelový model | LQ070T5BG01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 7.0 inch |
| rozlišení | 480(RGB)×234 |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 155.52×87.75 mm |
| obrys | 173×106 mm |
| povrch | Antiglare |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 60:1 (Min.) |
| zobrazit barvy | Full color |
| Doba odezvy | 30/50 (Typ.)(Tr/Td) |
| úhel pohledu | 65/65/40/65 (Typ.)(CR≥5)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhraní | Analog RGB + Composite Video (NTSC/PAL), 24 pins |
| vstupní napětí | 5.3/13/-16V (VSH/VGH/VGL) |
| aplikace | VDP |
