| PartNumber | LQ070Y1LG12 |
| Značka | SHARP |
| Velikost | 7.0 |
| aplikace | IA |
| Rozlišení | 800×480 |
| Složení | LCM |
| Jas | 350 |
| CR | |
| Barvy | 16.2M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | SHARP |
| panelový model | LQ070Y1LG12 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 7.0 inch |
| rozlišení | 800(RGB)×480 , WVGA |
| zobrazovací mód | Transmissive |
| aktivní oblast | 152.4×91.44 mm |
| obrys | 175.4×112.5 mm |
| povrch | |
| jas | 350 cd/m² (Typ.) |
| kontrastní poměr | |
| zobrazit barvy | 16.2M (6-bit + FRC), CIE193172% |
| Doba odezvy | |
| úhel pohledu | |
| typ lampy | 1 pcsCCFL |
| signálové rozhraní | LVDS |
| aplikace | IA |
