| PartNumber | LT070ME05000 |
| Značka | JDI |
| Velikost | 7.0 |
| aplikace | PAD |
| Rozlišení | 1200×1920 |
| Složení | LCM |
| Jas | 450 |
| CR | 1100:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | JDI |
| panelový model | LT070ME05000 |
| typ panelu | LTPS TFT-LCD , LCM |
| velikost panelu | 7.0 inch |
| rozlišení | 1200(RGB)×1920 , WUXGA |
| zobrazovací mód | IPS, Normally Black, Transmissive |
| aktivní oblast | 94.5×151.2 mm |
| obrys | 98.7×160.8×3.67 mm |
| povrch | |
| jas | 450 cd/m² (Typ.) |
| kontrastní poměr | 1100:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193172% |
| Doba odezvy | |
| úhel pohledu | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 5S4PWLEDEmbedded (LED Driver) |
| signálové rozhraní | MIPI (4 data lanes), 31 pins |
| vstupní napětí | 1.8/3.0/3.0V (Typ.)(IOVCC/VDD/VDDP) |
| aplikace | PAD |
