| PartNumber | M190EN04 V5 |
| Značka | AUO |
| Velikost | 19.0 |
| aplikace | DMPC |
| Rozlišení | 1280×1024 |
| Složení | LCM |
| Jas | 270 |
| CR | 700:1 |
| Barvy | 16.2M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | AUO |
| panelový model | M190EN04 V5 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 19.0 inch |
| rozlišení | 1280(RGB)×1024 , SXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 376.32×301.056 mm |
| obrys | 396×324×18 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 270 cd/m² (Typ.) |
| kontrastní poměr | 700:1 (Typ.) |
| zobrazit barvy | 16.2M (6-bit + FRC), CIE193172% |
| Doba odezvy | 5.6/2.4 (Typ.)(Tr/Td) |
| úhel pohledu | 70/70/75/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | DMPC |
| M190E5-L0G | Innolux | 19.0 | 1280×1024 |
| M190EG01 V2 | AUO | 19.0 | 1280×1024 |
| M190EG01 V3 | AUO | 19.0 | 1280×1024 |
| M190EG02 V4 | AUO | 19.0 | 1280×1024 |
| M190EG02 V7 | AUO | 19.0 | 1280×1024 |
| M190EG02 V9 | AUO | 19.0 | 1280×1024 |
| M190EN01 V1 | AUO | 19.0 | 1280×1024 |
| M190EN03 V0 | AUO | 19.0 | 1280×1024 |
| M190EN03 V2 | AUO | 19.0 | 1280×1024 |
| M190EN04 V5 | AUO | 19.0 | 1280×1024 |
| HM215WU3-100 | BOE | 21.5 | 1920×1080 |
| LM190E05-SL03 | LG Display | 19.0 | 1280×1024 |
| LM215WF4-TLA3 | LG Display | 21.5 | 1920×1080 |
| LM215WF4-TRA1 | LG Display | 21.5 | 1920×1080 |
| LM230WF5-TLH1 | LG Display | 23.0 | 1920×1080 |
| LM240WU7-SLB3 | LG Display | 24.0 | 1920×1200 |
| LTM190M2-L31 | Samsung | 19.0 | 1440×900 |
| LTM201M1-L01 | Samsung | 20.1 | 1680×1050 |
| M190CGE-L20 | Innolux | 19.0 | 1440×900 |
| MT190EN02 V.W | Innolux | 19.0 | 1280×1024 |
