| PartNumber | M236H3-L05 |
| Značka | Innolux |
| Velikost | 23.6 |
| aplikace | DMPC |
| Rozlišení | 1920×1080 |
| Složení | LCM |
| Jas | 300 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | CHIMEI INNOLUX |
| panelový model | M236H3-L05 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 23.6 inch |
| rozlišení | 1920(RGB)×1080 , FHD |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 521.28×293.22 mm |
| obrys | 544.8×320.5 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit) |
| Doba odezvy | 1.5/3.5 (Typ.)(Tr/Td) |
| úhel pohledu | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 120Hz |
| typ lampy | 12S6PWLEDWithout Driver |
| signálové rozhraní | LVDS (4 ch, 8-bit), 66 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | DMPC |
