| PartNumber | PT035TN23 V.1 |
| Značka | Innolux |
| Velikost | 3.5 |
| aplikace | DSC |
| Rozlišení | 320×240 |
| Složení | LCM |
| Jas | 350 |
| CR | 500:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | INNOLUX |
| panelový model | PT035TN23 V.1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 320(RGB)×240 , QVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 70.08×52.56 mm |
| obrys | 76.9×64.4×4.43 mm |
| povrch | Antiglare |
| jas | 350 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 9/16 (Typ.)(Tr/Td) |
| úhel pohledu | 65/65/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 6S1PWLED |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit) + SPI, 60 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | DSC |
| CT035TN02 | Innolux | 3.5 | 320×480 |
| EL160.80.50 IN LC CC | Lumineq | 3.5 | 160×80 |
| LQ035Q5DG01 | SHARP | 3.5 | 320×240 |
| LTV035QV-F04 | Samsung | 3.5 | 320×240 |
| NL2432HC22-41K | NLT | 3.5 | 240×320 |
| PT035TN01 V.3 | Innolux | 3.5 | 320×240 |
| PT035TN01 V.6 | Innolux | 3.5 | 320×240 |
| PT035TN23 V.1 | Innolux | 3.5 | 320×240 |
| PT035TN23 V.3 | Innolux | 3.5 | 320×240 |
| TD035SHED1 | TPO | 3.5 | 480×640 |
| A015AN04 V6 | AUO | 1.5 | 280×220 |
| A017CN01 V1 | AUO | 1.7 | 480×240 |
| A025DL02 V5 | AUO | 2.5 | 320×240 |
| A030DN01 V9 | AUO | 3.0 | 320×240 |
| LQ035JC211 | Innolux | 3.5 | 320×240 |
| LS025A8DZ01S | SHARP | 2.5 | 320×240 |
| PA025XSF | E Ink | 2.5 | 480×234 |
| TD030MHEB3 | TPO | 3.0 | 320×240 |
| TD030WHEA1 | TPO | 3.0 | 320×240 |
| TM035KDH03-79 | Tianma | 3.5 | 320×240 |
