| PartNumber | PW070DS1T2 |
| Značka | E Ink |
| Velikost | 7.0 |
| aplikace | VDP |
| Rozlišení | 480×234 |
| Složení | LCM |
| Jas | |
| CR | 150:1 |
| Barvy | |
| Podsvícení | CCFL |
| Rozhraní | Analog |
| značka panelu | PVI |
| panelový model | PW070DS1T2 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 7.0 inch |
| rozlišení | 480(RGB)×234 |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 154.08×87.05 mm |
| obrys | 166.9×101.8 mm |
| povrch | Antiglare, Hard coating |
| jas | |
| kontrastní poměr | 150:1 (Typ.) |
| zobrazit barvy | |
| Doba odezvy | 30/50 (Max.)(Tr/Td) |
| úhel pohledu | 55/55/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 1 pcsCCFLWithout Driver |
| rohs: | |
| aplikace | VDP |
