| PartNumber | TD020THEG1 |
| Značka | TPO |
| Velikost | 2.0 |
| aplikace | DSC |
| Rozlišení | 640×240 |
| Složení | LCM |
| Jas | 300 |
| CR | 300:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | Serial RGB |
| značka panelu | TPO |
| panelový model | TD020THEG1 |
| typ panelu | LTPS TFT-LCD , LCM |
| velikost panelu | 2.0 inch |
| rozlišení | 640×240 , HVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 40.672×30.48 mm |
| obrys | 46.1×40.96 mm |
| povrch | Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 300:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Dithering) |
| Doba odezvy | 13/22 (Typ.)(Tr/Td) |
| úhel pohledu | 40/40/20/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 1 pcsWLEDWithout Driver |
| signálové rozhraní | Analog RGB + LVDS (1 ch, 6-bit), 40 pins |
| vstupní napětí | 3.0V (Typ.) |
| aplikace | DSC |
