| PartNumber | VVX10F011B00 |
| Značka | Panasonic |
| Velikost | 10.1 |
| aplikace | PAD |
| Rozlišení | 1920×1200 |
| Složení | LCM |
| Jas | 650 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | eDP |
| značka panelu | Panasonic |
| panelový model | VVX10F011B00 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 10.1 inch |
| rozlišení | 1920(RGB)×1200 , WUXGA |
| zobrazovací mód | IPS, Normally Black, Transmissive |
| aktivní oblast | 217.44×135.9 mm |
| obrys | 228.86×152.5×4.18 mm |
| povrch | Hard coating, Antireflection |
| jas | 650 cd/m² (Min.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193150% |
| Doba odezvy | 35 (Max.)(Tr+Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 10S6PWLEDEmbedded (LED Driver) |
| signálové rozhraní | eDP (2 Lanes), 30 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | PAD |
| A101VW01 V0 | AUO | 10.1 | 800×480 |
| AM-19201200B1TZQW-T00 | AMPIRE | 10.1 | 1920×1200 |
| B101UAN01.E | AUO | 10.1 | 1920×1200 |
| CLAA101FP01 XG | CPT | 10.1 | 1920×1200 |
| N101ICG-L11 | Innolux | 10.1 | 1280×800 |
| VVX10F002A00 | Panasonic | 10.1 | 1920×1200 |
| VVX10F004B00 | Panasonic | 10.1 | 1920×1200 |
| VVX10F008B00 | Panasonic | 10.1 | 1920×1200 |
| VVX10F011B00 | Panasonic | 10.1 | 1920×1200 |
| VVX10F034N00 | Panasonic | 10.1 | 1920×1200 |
| B080XAN03.0 | AUO | 7.9 | 768×1024 |
| B101EVT04.0 | AUO | 10.1 | 1280×800 |
| B101UAN07.0 | AUO | 10.1 | 1200×1920 |
| HJ101NA-02C | Innolux | 10.1 | 1280×800 |
| HV070WS1-105 | HYDIS | 7.0 | 1024×600 |
| HX104X01-210 | HYDIS | 10.4 | 1024×768 |
| HX104X02-100 | HYDIS | 10.4 | 1024×768 |
| TFTMD089030 | JDI | 8.9 | 2560×1600 |
| TV101WXM-NP1 | BOE | 10.1 | 1280×800 |
| VVX10F004B00 | Panasonic | 10.1 | 1920×1200 |
