| PartNumber | YX035CM31 |
| Značka | |
| Velikost | 3.5 |
| aplikace | HHP |
| Rozlišení | 320×240 |
| Složení | LCM |
| Jas | 800 |
| CR | 400:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | Parallel/Serial |
| značka panelu | |
| panelový model | YX035CM31 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 320(RGB)×240 , QVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 70.08×52.56 mm |
| obrys | 76.9×63.9 mm |
| povrch | Antiglare (Haze 20%) |
| jas | 800 cd/m² (Typ.) |
| kontrastní poměr | 400:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit) |
| Doba odezvy | 10/15 (Typ.)(Tr/Td) |
| úhel pohledu | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 5S2PWLEDWithout Driver |
| signálové rozhraní | Digital RGB (8/24-bit) + SPI, CCIR601/656, 54 pins |
| vstupní napětí | 3.3/13.9/13.6V (Typ.)(VCC/VGH/VGL) |
| aplikace | HHP |
