| PartNumber | B101XAN02.0 |
| Značka | AUO |
| Velikost | 10.1 |
| aplikace | PAD |
| Rozlišení | 1366×768 |
| Složení | LCM |
| Jas | 250 |
| CR | 800:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | AUO |
| panelový model | B101XAN02.0 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 10.1 inch |
| rozlišení | 1366(RGB)×768 , WXGA |
| zobrazovací mód | AHVA, Normally Black, Transmissive |
| aktivní oblast | 222.341×125.568 mm |
| obrys | 235.01×138.95×4.7 mm |
| povrch | Glare (Haze 0%), Hard coating (3H) |
| jas | 250 cd/m² (Typ.) |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC), CIE193150% |
| Doba odezvy | 15/10 (Typ.)(Tr/Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4 stringsWLEDWithout Driver |
| signálové rozhraní | MIPI (4 data lanes), 39 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | PAD |
