| PartNumber | LB035Q01-TJ01 |
| Značka | LG Display |
| Velikost | 3.5 |
| aplikace | PND |
| Rozlišení | 320×240 |
| Složení | CELL |
| Jas | 0 |
| CR | 300:1 |
| Barvy | 16.7M |
| Podsvícení | No B/L |
| Rozhraní | TTL |
| značka panelu | LG.Philips LCD |
| panelový model | LB035Q01-TJ01 |
| typ panelu | a-Si TFT-LCD , CELL |
| velikost panelu | 3.5 inch |
| rozlišení | 320(RGB)×240 , QVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 70.08×52.56 mm |
| obrys | 78.1×62.95×1.53 mm |
| povrch | Hard coating |
| kontrastní poměr | 300:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit) |
| Doba odezvy | 30 (Typ.)(Tr+Td) |
| úhel pohledu | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 70Hz |
| signálové rozhraní | TTL (1 ch, 8-bit), 45 pins |
| vstupní napětí | 3.3/5.0V (Typ.)(VDD/AVDD) |
| rohs: | |
| aplikace | PND |
