| PartNumber | LQ050T5DG02 |
| Značka | SHARP |
| Velikost | 5.0 |
| aplikace | CNS |
| Rozlišení | 400×240 |
| Složení | LCM |
| Jas | 600 |
| CR | |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | SHARP |
| panelový model | LQ050T5DG02 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.0 inch |
| rozlišení | 400(RGB)×240 , WQVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 108×64.8 mm |
| obrys | 120.6×75.2 mm |
| povrch | |
| jas | 600 cd/m² (Typ.) |
| kontrastní poměr | |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | |
| úhel pohledu | |
| typ lampy | WLED |
| signálové rozhraní | CMOS (1 ch, 6-bit) |
| rohs: | |
| aplikace | CNS |
