| PartNumber | LTE283QV-F01 |
| Značka | Samsung |
| Velikost | 2.8 |
| aplikace | PDA |
| Rozlišení | 320×240 |
| Složení | LCM |
| Jas | 250 |
| CR | 350:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | SAMSUNG |
| panelový model | LTE283QV-F01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 2.8 inch |
| rozlišení | 320(RGB)×240 , QVGA |
| zobrazovací mód | PVA, Normally Black, TMR |
| aktivní oblast | 57.59×43.19 mm |
| obrys | 64.4×56.5 mm |
| povrch | |
| jas | 250 cd/m² (Typ.) |
| kontrastní poměr | 350 : 1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit) |
| Doba odezvy | 35 (Typ.)(Tr+Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 5S1PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 8-bit) + SPI, 45 pins |
| vstupní napětí | 2.8/2.8V (Typ.)(VDC/VCC) |
| aplikace | PDA |
| 28QVF1J | SII | 2.8 | 240×320 |
| 28QVF2H | SII | 2.8 | 240×320 |
| 28QVF2J | SII | 2.8 | 240×320 |
| ET028002DMU | EDT | 2.8 | 240×320 |
| F-55472GNFJ-SLW-AAN | Kyocera | 2.8 | 128×64 |
| LTE283QV-F01 | Samsung | 2.8 | 320×240 |
| LTP283QV-F04 | Samsung | 2.8 | 240×320 |
| TFT240320-237-E | Other | 2.8 | 240×320 |
| TM028HBHG02 | Tianma | 2.8 | 240×320 |
| LTP500GV-F01 | Samsung | 5.0 | 480×640 |
| NL2432DR22-02B | NLT | 3.5 | 240×320 |
| NL2432DR22-11B | NLT | 3.5 | 240×320 |
| NL2432HC22-25E | NLT | 3.5 | 240×320 |
| NL2432HC22-41B | NLT | 3.5 | 240×320 |
| NL2432HC22-41K | NLT | 3.5 | 240×320 |
| TD035STEB2 | TPO | 3.5 | 240×320 |
| TD035STED7 | TPO | 3.5 | 240×320 |
| TM038QV-67A02E | SANYO | 3.8 | 320×240 |
| TX09D23VM1CAA | KOE | 3.5 | 240×320 |
