| PartNumber | LTP500GV-F01 |
| Značka | Samsung |
| Velikost | 5.0 |
| aplikace | PDA |
| Rozlišení | 480×640 |
| Složení | LCM |
| Jas | 200 |
| CR | 250:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | SAMSUNG |
| panelový model | LTP500GV-F01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.0 inch |
| rozlišení | 480(RGB)×640 , VGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 75.6×100.8 mm |
| obrys | 83.84×113.2×4.8 mm |
| povrch | |
| jas | 200 cd/m² (Typ.) |
| kontrastní poměr | 250:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193140% |
| Doba odezvy | 35 (Typ.)(Tr+Td) |
| úhel pohledu | 40/30/50/50 (Min.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 3S4PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit), 60 pins |
| vstupní napětí | 3.3/8.0/16.0/-8.4V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplikace | PDA |
| ACX534AKM-2 | SONY | 5.0 | 800×600 |
| AT050TN34 V.1 | Innolux | 5.0 | 480×272 |
| CLAA050JA01CT | CPT | 5.0 | 480×272 |
| LMS500HF06 | Samsung | 5.0 | 480×272 |
| LQ050T1SX02 | SHARP | 5.0 | 1080×1920 |
| LQ050T5DW02 | SHARP | 5.0 | 400×240 |
| LTE052T-45 | Philips | 5.0 | 320×234 |
| LTP500GV-F01 | Samsung | 5.0 | 480×640 |
| PA050XSG | E Ink | 5.0 | 320×234 |
| TM050NDH01 | Tianma | 5.0 | 480×272 |
| ACX502BMU-7 | SONY | 3.5 | 240×320 |
| LQ035Q7DH05 | SHARP | 3.5 | 240×320 |
| LS037V7DD05 | SHARP | 3.7 | 480×640 |
| LTP500GV-F01 | Samsung | 5.0 | 480×640 |
| NL2432DR22-11B | NLT | 3.5 | 240×320 |
| NL2432HC22-23B | NLT | 3.5 | 240×320 |
| NL2432HC22-41K | NLT | 3.5 | 240×320 |
| NL4864HL11-01B | NLT | 3.5 | 480×640 |
| TD035STED4 | TPO | 3.5 | 240×320 |
| TX09D23VM1CAA | KOE | 3.5 | 240×320 |
