| PartNumber | TM030LDHT1 |
| Značka | Tianma |
| Velikost | 3.0 |
| aplikace | HHP |
| Rozlišení | 240×400 |
| Složení | LCM |
| Jas | 130 |
| CR | 100:1 |
| Barvy | 65K/262K |
| Podsvícení | WLED |
| Rozhraní | CPU/RGB/SPI |
| značka panelu | TIANMA |
| panelový model | TM030LDHT1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 3.0 inch |
| rozlišení | 240(RGB)×400 , WQVGA |
| zobrazovací mód | ECB, Normally White, Transflective |
| aktivní oblast | 38.88×64.8 mm |
| obrys | 47.28×76.4 mm |
| povrch | Clear, Hard coating (3H) |
| jas | 130 cd/m² (Typ.) |
| kontrastní poměr | 100:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| zobrazit barvy | 65K/262K , CIE193134% |
| Doba odezvy | 35 (Typ.)(Tr+Td) |
| úhel pohledu | 40/45/55/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4S1PWLEDWithout Driver |
| signálové rozhraní | CPU/RGB/SPI, 45 pins |
| vstupní napětí | 2.8/2.8V (Typ.)(IOVCC/VCC) |
| aplikace | HHP |
| C-51505NFQJ-LW-ALN | Kyocera | 3.0 | 20×2 |
| C030DW01 V0 | AUO | 3.0 | 320×240 |
| LH300Q01-ED01 | LG Display | 3.0 | 320×240 |
| LS030B3UX01D | SHARP | 3.0 | 240×400 |
| LS030B3UX07 | SHARP | 3.0 | 240×400 |
| TM030CDH51-00 | Tianma | 3.0 | 320×240 |
| TM030LBHT1 | Tianma | 3.0 | 240×400 |
| TM030LDHT1 | Tianma | 3.0 | 240×400 |
| TM030LDHT2 | Tianma | 3.0 | 240×400 |
| TM030ZDHG01 | Tianma | 3.0 | 320×320 |
| 28QVF2H | SII | 2.8 | 240×320 |
| COM22H2P16ULC | ORTUSTECH | 2.2 | 240×320 |
| LQ030B7DD01 | SHARP | 3.0 | 320×320 |
| LQ043T1DG03 | SHARP | 4.3 | 480×272 |
| LQ043T1DG03B | SHARP | 4.3 | 480×272 |
| LQ043T1DG28 | SHARP | 4.3 | 480×272 |
| S035V01 | CDTECH | 3.5 | 480×640 |
| TFTMD030011 | JDI | 3.0 | 720×480 |
| TX09D70VM1CEA | KOE | 3.5 | 240×320 |
| YX035CM31 | 3.5 | 320×240 |
