| PartNumber | TD070WGCB2 |
| Značka | TPO |
| Velikost | 7.0 |
| aplikace | CNS |
| Rozlišení | 854×480 |
| Složení | LCM |
| Jas | 400 |
| CR | 450:1 |
| Barvy | 262K |
| Podsvícení | CCFL |
| Rozhraní | TTL |
| značka panelu | Toppoly |
| panelový model | TD070WGCB2 |
| typ panelu | LTPS TFT-LCD , LCM |
| velikost panelu | 7.0 inch |
| rozlišení | 854(RGB)×480 , FWVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 155×87.12 mm |
| obrys | 166.4×106.3×8.9 mm |
| povrch | |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 450:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 7/18 (Typ.)(Tr/Td) |
| úhel pohledu | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit), 40 pins |
| vstupní napětí | 3.3V (Typ.)(VDD) |
| aplikace | CNS |
